Core-Type Roll T-Shirt Bag Making Machine

Technical Specifications

• Model Year: 2020
• Brand: Hemingstone
• Machine Type: Core Roll T-Shirt Bag Making Machine
• Production System: 2-Lane – Fully Automatic
• Control System: Servo Controlled
• Cutting System: Servo-Controlled Rotary Cutting
• Production Speed: 100–360 cycles/min
• Film Line Speed: 160 m/min
• Bag Length: 300–700 mm
• Bag Width: 150–300 mm × 2 Lanes
• Maximum Film Width: 1000 mm
• Maximum Roll Diameter: 170 mm
• Core Outer Diameter: 35.5 mm
• Core Options: 200 / 300 mm
• Raw Material Compatibility: LDPE / HDPE / Recycled Film / Bio Film
• Total Power: 25 kW
• Machine Location: Adana Branch

Key Features

• Dual-Lane Production System: Provides high capacity and low unit production costs by producing simultaneously on 2 lanes.
• High-Speed Performance: Suitable for high-volume production with a production speed of 100–360 cycles/min and a film line speed of 160 m/min.
• Servo-Controlled Rotary Cutting: Provides precise perforation, clean tearing and stable production performance.
• Automatic Core Roll Winding: Compatible with paper cores with a 35.5 mm outer diameter and supports 200 / 300 mm core options.
• Wide Operating Range: Adapts to different production requirements with bag lengths of 300–700 mm and bag widths of 150–300 mm on each lane.
• Wide Raw Material Compatibility: Can operate with LDPE and HDPE as well as recycled and bio film varieties.
• Fully Automatic Production: Its servo-controlled structure provides fast, stable and efficient mass production.

Applications

• Supermarket roll bags
• Produce section bags
• Chain store roll bags
• Core roll t-shirt bag production
• High-capacity industrial bag production

Condition

• 2020 model
• Ready at our Adana branch
• Available for on-site inspection
• Can be tested in operation
• Contact us for detailed technical information and the current price
