Hualian FBK-332C Automatic Bag Sewing and Bag Closing Machine

Hualian FBK-332C is an industrial bag sewing and sealing machine designed for the automatic closing of kraft paper bags, paper bags with PE inner liners, and paper/plastic composite bags. It automatically performs cutting, sewing, edge binding, heat sealing, pressing, and counting operations, making it ideal for integration into high-volume production and packaging lines.

Technical Specifications

• Model: FBK-332C
• Power Supply: AC 380 V / 50 Hz
• Total Power: 6.5 kW
• Transmission Power: 0.75 kW
• Sewing Machine Motor Power: 0.37 kW
• Heating Power: 0.5 × 10 kW
• Sealing Speed: 8.5 m/min
• Sealing Center Height: 800–1400 mm
• Temperature Range: 0–400 °C
• Air Pressure: 0.6 MPa
• Dimensions: 3030 × 950 × 1800 mm
• Net Weight: 600 kg
