Fully Automatic Plastic Cap Making Machine PLS32Q

CSA Endüstri’s MayCUP PLS32Q model is a fully automatic cap production machine developed for manufacturing plastic caps from HIPS, PET, PS, and PVC films. It produces caps from material with a thickness of 0.15–0.55 mm, up to 150 mm in diameter and 30 mm in depth, with a capacity of approximately 96–384 pieces/minute for 60 mm caps. The automatic forming, cutting, and product collection systems operate on a single production line.

Product Features

• PLS32Q Fully Automatic Plastic Cap Production Machine Technical Specifications
• Maximum Mold Width: 410 × 150 mm
• Processable Material Thickness: 0.15–0.55 mm (HIPS, PET, PS, PVC, etc. plastic film)
• Manufacturable Cap Diameter / Depth: Max. 150 mm / 30 mm
• Mold Cutting Speed: 8–32 Times/Min.
• Production Capacity: 96–384 pcs./min. (approximately for 60 mm caps)
• Material Strip Width: Max. 430 mm
• Product Collection Section: Yes
• Total Power: 4.6 kW
• Power Supply: 380 V, 3-phase, 50 Hz
• Weight (Packed/Unpacked): 1,000 kg / 800 kg
• Machine Dimensions: 2300 × 1000 × 1900 mm
• Water Supply Requirement: Water pressure 0.2 MPa; water inlet 0.3 m³/h
• Air Pressure Requirement: Air pressure 0.5–0.7 MPa; air inlet 0.2 m³/min.
• Perforated/Non-Perforated Cap Production: Yes
