Fully Automatic Paperboard Bowl and Rotary Box Making Machine MYC80C

CSA Endüstri MayCUP MYC80C Fully Automatic Paper Bowl and Döner Box Machine is a fully automatic paper bowl machine developed for the production of soup bowls, salad bowls, ice cream cups, and Döner Boxes. It offers a production range of 12-20 OZ and a stable production capacity of 50-70 pieces per minute. PLC-controlled full automation, servo bottom paper feeding, automatic hydraulic bottom paper lifting, and an optional robotic arm or blow-out collection system support the controlled production of various food packaging products.

Product Features

• Model: MayCUP MYC80C
• Raw Material: Single / Double PE
• Processable Paper Weight: 140-350 g/m² PE
• Operating Voltage: 380 V / 50 Hz
• Motor Type: Inverter
• Air Pressure Requirement: 0.6 MPa, 0.6 m³/min.
• Chassis Type: Reinforced chassis
• Transmission System: Extra-hardened gear and shaft system
• Side Paper Suction System: 4-cup suction system
• Lubrication System: Automatic lubrication and filtration system
• Silicone Lubrication System: Automatic
• Conveyor Bottom Paper Waste Cutter: Included
• Bottom Paper Feeding: Servo electronic motor
• Safety Frame: Yes
• Mold Size Range: 12-20 OZ
• Side Paper Sealing: Ultrasonic
• Side Paper Preheating System: Yes, 1 unit; for excellent sealing
• Speed: 50-70 pcs/min. / 3,000-4,200 pcs/hour
• Total Power: 15 kW
• Weight: 2,800 kg
• Dimensions: 2780 × 1460 × 2050 mm
• Number of Cup Molds: 8 aluminum cup molds
• Bottom Adhesive Follower Units: 4 units in total, including 1 air-assisted snail-type unit and 2 ceramic heaters; provides excellent adhesion and sealing.
• Control Type: PLC control, full automation
• Collection System: Robotic arm / Blow-out system (O)
• Bottom Paper Lifting System: Automatic hydraulic system
