CU80 Cable Recycling Machine

The CU80 Cable Recycling Machine is a high-capacity cable granulation and separation system designed for industrial recycling facilities. Equipped with advanced granulation, air separation, and fan technologies, it recovers copper, aluminum, and plastic components with separation efficiency of up to 99.6%. Its intelligent PLC control system and touchscreen interface allow operators to manage all machine functions and production data from a single control panel.

The machine can be operated with a manual conveyor feeding system or integrated with the SSH Series Pre-Shredder to create a fully automated recycling line. Its heavy-duty steel construction, premium mechanical components, and CE-compliant design ensure reliable, safe, and long-lasting operation in demanding industrial environments.

Technical Specifications

• Processing Capacity: Up to 800 kg/hour
• Total Power: 80 kW (107.2 HP)
• Granulator Motor: 55 kW (73.7 HP)
• Blade Configuration: 40 + 4 blades
• Machine Dimensions (L × W × H): 5,280 × 2,000 × 2,860 mm
• Total Weight: 5,000 kg (11,020 lb)

Key Features

• Up to 99.6% copper and plastic separation efficiency
• High-capacity granulation and separation technology
• Intelligent PLC automation with touchscreen control panel
• Manual or automatic conveyor feeding options
• Compatible with the SSH Series Pre-Shredder for fully automated operation
• Heavy-duty steel frame construction
• Low maintenance requirements and high operating efficiency
• CE-certified design for safe industrial operation

Contact us for technical information, pricing, and customized cable recycling solutions tailored to your production requirements.
